Flat water hose

Hose type: Mandrel hose, winding structure
Construction:
Inner lining: NR+SBR
Reinforcement: High-strength spiral textile cord
Outer layer: NR+SBR

DeepSee® Flat Water Hose is an ideal choice for low-pressure and temporary water supply, drainage, and washdown in agriculture, construction, mining, and general industry. Its working pressure is usually no more than 10bar. Our water rubber hose simplifies storage and transport and ensures safe water delivery.

In comparison with common round water rubber hoses, this layflat water hose is softer and less bulky. It lies smoothly, resists kinks, and provides greater flexibility. Its flat construction makes it easy to coil, store, and transport, therefore it’s perfect for light-duty applications that require frequent deployment and have limited storage spaces.

Our flat water hoses are lightweight yet durable. The hose reduces operator fatigue without sacrificing strength. It withstands abrasion, UV rays, ozone and tough outdoor conditions while maintaining smooth water flow and dependable performance.

Looking for wholesale water transfer hose with a compact and space-saving design? DeepSee’s lay flat water hose is the right answer.

DeepSee® Flat Water Hose Specifications
(Safety Factor 2:1)

mm	inch	mm	bar	psi	bar	psi	kg/m	m	mm
64	2½	74.8	10	150	20	300	1.71	20	2.5
76	3	86.8					1.99	20	2.5
89	3½	99.8					2.32	20	2.5
102	4	112.8					2.63	20	2.5

DeepSee® Flat Water Hose Specifications
(Safety Factor 3:1)

mm	inch	mm	bar	psi	bar	psi	kg/m	m	mm
51	2	61.8	5	75	15	225	1.33	20	2.5
64	2½	74.8					1.64	20	2.5
76	3	86.8					1.92	20	2.5
89	3½	99.8					2.22	20	2.5
102	4	112.8					2.53	20	2.5
127	5	138.2					3.15	20	2.5
152	6	165.6					4.89	20	2.5
203	8	216.6					6.46	20	2.5
304	12	318.4					10.04	20	2.5

I.D		O.D	W.P		B.P		Weight	Max. Length	Inner Rubber Thickness
mm	inch	mm	bar	psi	bar	psi	kg/m	m	mm
19	¾	29.4	10	150	30	450	0.54	20	2.5
22	⅞	32.4					0.61	20	2.5
25	1	35.4					0.67	20	2.5
28	1	38.4					0.74	20	2.5
32	1¼	42.4					0.83	20	2.5
35	1	45.4					0.89	20	2.5
38	1½	48.8					1.03	20	2.5
40	1	50.8					1.07	20	2.5
48	1⅞	58.8					1.26	20	2.5
51	2	61.8					1.33	20	32.5

For other specifications or special requirements, please contact our team to customize.
